    CO2 30000bph Laser Bottle Code Printer Date Coding Machine 180kw

    Ask Lasest Price
    Brand Name : Fill Drink
    Model Number : JG-100
    Certification : CE ISO
    Price : 6350USD
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 100 sets per month
    Delivery Time : 15 days
    • Product Details
    • Company Profile

    CO2 30000bph Laser Bottle Code Printer Date Coding Machine 180kw

    CO2 Automatic 30000bph Capacity For Bottle Laser Code Jet Printer


    Characters:

    CO2 Laser Printer--- For products in assembly line & manually coding, printing and marking.
    Our CO2 laser marking machines are powerful and versatile, they deliver flexible, high speed, high quality coding across a wide variety of materials with the ability to produce multiple lines of text. Our laser marking machines are designed to fit in limited spaces and integrate into a variety of production lines. We now have the users all over the world. Our honored clients use laser marking machine to printing on plastic (PET) bottles, printing on paper labels and printing on glass bottles.


    The details of product:



    Technical parameters:

    Laser typeMetal tube carbon dioxide laser
    Laser power30W
    Laser headLength: 750mm Width: 160mm Height: 180mm
    Whole machine Power800W
    Print line speed≤150m/min
    Number of flight mark lines10X 10
    Minimum line width0.15mm
    Minimum character0.40mm
    Repeating accuracy±0.01mm
    Laser wave length10.6µm
    Divergence angle miliradian7.5mrad
    Fastest printing line speed7000mm/s
    Number of characters printed per second1200bps
    Focal length120mm
    RowsAny rows
    Character height0.5~100mm
    Print informationLine height 0.5-100mm,Max 300mm
    Print range90*300mm
    Cooling wayAir cooling
    Environment literature5-45℃
    Environment humidity90% non-condensing
    Print contentEnglish letter,Arabic numerals and patterns
    Optimal print interval≥1mm
    Power SupplyAc 110V-220V/50HZ,5A
    Humidity10%-90%
    Communication interfaceUSB,RS232/485,Ethernet
    Protection degreeIP54
    Detection settingsPhotoelectric sensor,PNP/12V
    Size and weight:

    Laser head 850*170*195mm 25KG

    Laser bracket 1500*600*580mm 22KG

    Controller 275*210*30mm 2KG


    Service:
    1. we can send you the video of the running machine.
    2. you are always welcome to come to visit our factory, and you may see the operation of the machines here . We will make the arrangement to pick you up when you come .
    3. If we get the permission of the customer who has brought the machines from us ,we can tell you their contact information, you can go to visit their factory.


    Customized service
    1. we can design the machines according your requirements(material ,power,filling type,the kinds of the bottles, and so on).
    2. at the same time we will give you our professional suggestion .


    After-sales service
    1. we will provide the bill of load on time to make sure you can get the machine quickly
    2. when you finish the Preparation conditions ,our engineer will go to your factory for the installation, testing and also training .
    3. we provide one year warranty with spare parts free.
